LightSpeed Lift Gait Kinetics Analysis

Performed by: Jena Ogston, PhD, PT; Jennifer Bradley, SPT, Kayla Findlay, SPT; Breanna Lohn, SPT; Derek Swenson, SPT from the College of St. Scholastica Department of Physical Therapy; Class of 2015


Body weight supported treadmill training is commonly used in clinical practice with broad applicability including gait, endurance, and balance interventions1. A novel treadmill system, the LightSpeed®, has been developed by a physical therapist to capture the benefits of body weight support for both clinical and recreational use. The LightSpeed® has been utilized for physical training in running and for individuals with orthopedic pathologies. The device offers several proposed benefits including decreased impact forces, decreased risk of repetitive stress injuries associated with endurance training, and partial unweighting for gradual return to weight bearing activity after injury. 1-2, 4-6.


To determine the effect of the LightSpeed® treadmill system on contact time and kinetic parameters in healthy, young adults while walking and running on a treadmill.

Hypothesis: Decreased kinetic forces will be observed during walking and running in the LightSpeed® body support system.


Researchers recruited 15 healthy participants who reported a minimum of 5 hours experience of treadmill running. The subjects determined a self-selected walking and running speed during a 2-3 minute warm-up period. Participants then donned LightSpeed® neoprene shorts and were fitted with PEDAR® insoles. Subjects walked/ran at a self-selected pace with full weight trials followed by unweighting walk/run trials while in the LightSpeed®. A total of 20 sequential steps were collected randomly during each of the 2 minute bouts. A paired t-test (SPSS®) was conducted comparing the differences between the weighted and unweighted walking and running conditions.


Demographics Mean (range)
Age (years) 27.15 (20-44)
BMI (Kg/m2) 23.1 (20.6-25.7)
Walking Speed (mph) 2.99 (2.4-3.5)
Running Speed (mph) 6.06 (5.2-7.0)
Walking Weighted Unweighted % Difference
Contact Time (ms) 632.2 615.2 - 2.7%*
Force-time integral (N-s) 47.9 36.3 - 24.2%*
Peak-time integral (N-s/m2) 89.3 76.2 - 14.7%*
Peak Pressure (N/m2) 259.2 225.7 - 12.9%*
Maximum Force normalized to body weight (N) 108.0 90.8 - 15.9%*
Running Weighted Unweighted % Difference
Contact Time (ms) 273.2 247.0 - 9.6%*
Force-time integral (N-s) 31.5 26.5 - 15.9%*
Pressure-time integral (N-s/m2) 54.2 44.5 - 17.9%*
Peak Pressure (N/m2) 318.6 289.0 - 9.3%*
Maximum Force normalized to body weight (N) 181.4 160.5 - 11.5%*


Unweighted treadmill devices provide a means of exercise for those with cardiovascular, neuromuscular and/or musculoskeletal pathologies 1-4, 6-7. Very little research has investigated the actual kinetic and kinematic changes that occur during unweighted gait. The results of this study support the hypothesis regarding decreased impact forces during the use of the LightSpeed® unweighting treadmill device. All force and pressure measurements taken during unweighted conditions were significantly decreased by an average of 15% as compared to weighted trials. The findings of this study have clinical implications for the physical therapist in that the LightSpeed® is an affordable unweighting device compared to those of other manufacturers, and may provide a means of decreasing risk for injury amongst healthy individuals. Future research in this area should focus on evaluating the efficacy of the LightSpeed® as an intervention and further evaluate the kinetic and kinematic effects on varied patient populations.


The LightSpeed® created both statistically and clinically meaningful significant unweighting effects in the realms of pressure and force during both walking and running. This body weight support system may reduce lower extremity joint reaction forces, and thus serve as an effective gait intervention for both prevention and rehabilitation.


  • Giangregorio LM, Thabane L, Debeer J, Farrauto L, McCartney N, Adachi JD, & Papaioannou A. Body weightsupported
    treadmill training for patients with hip fracture: A feasibility study. Archives of Physical Medicine and
    Rehabilitation. 2000; 90(12): 2125-2130. doi: 10.1016/j.apmr.2009.06.022.
  • Hoffman MD, & Donaghe BS. Physiological responses to body weight-support treadmill exercise in healthy adults.
    2011; Archives of Physical Medicine and Rehabilitation. 2011; 92 (6): 960-966. doi: 10.1016/j.apmr.2010.12.035.
  • Lee HJ, Cho KH, & Lee WH. The effects of body weight support treadmill training with power-assisted functional
    electrical stimulation on functional movement and gait in stroke patients. American Journal of Physical Medicine
    and Rehabilitation. 2013; 92 (12): 1051-1059.
  • Lienbenberg J, Scharf J, Forrest D, Dufek JS, Masumoto K & Mercer JA. Determination of muscle activity during
    running at reduced body weight. Journal of Sport Sciences. 2011; 29 (2): 207-214.
  • LightSpeed Running and Rehabilitation. 2013. Retrieved from Assessed March 3, 2014.
  • Millslagle D, Levy M, & Matack N. Comparative kinematics measures in treadmill running with or without body
    weight support in runners. Journal of Sport Science and Medicine, 2005; 4 (4): 583-589.1.
  • Moriello G, Haller M, Adams A, Cable L, Stone K & Ingegni A. Running outcomes following an intensive exercise
    program in those with brain injuries. Clinical Kinesiology. 2013; 67 (4): 44-54.
